PSI 2430 American Fully Automatic Osmometer – High Cost-Effective & Affordable-Huatai Hehe (Beijing) Trading Co., Ltd

01Product Description

PSI was founded in 1963 (60 years ago) with the aim of designing and manufacturing freezing point osmometers and freezing point meters with high precision, accuracy, and reliability. Our osmometers and freezing point meters can be used in clinical laboratories, research, small animal testing, drug quality control, intravenous injection solutions, beverages, reagents, eye solutions, incoming inspection, dairy products, petroleum, and many other fields. PSI has pioneered freezing point penetration measurement technology in many aspects, including the development of a simple, non interactive calibration program for all of our instruments. Due to the characteristics of the freezing point principle, it is highly suitable for applications such as general chemical analysis, drug abuse, quality control, drug development, reagent development, and industrial testing. We are at the forefront of the market in providing smaller 10 µ L sample osmometers. We also offer a relatively complete series of osmotic pressure gauges to meet the needs of each user. We have received a call from a customer requesting to repair an instrument they have been using in the laboratory for 25 years or more. This also confirms that the advantage of our instrument in terms of quality is obvious.

1. Sample capacity of 24, testing time of approximately 30 minutes

2. The sample size is 30ul, which not only saves samples but also maintains repeatability

3. Transparent sample observation window for easy observation. The sample has an independent space and is equipped with a sample protection plate to reduce contamination

4. The sample tube can be reused and is easy to clean

5. Multiple calibration methods to meet different user requirements

6. It has the function of cleaning sample probes

7. The standard solution is bottled in 125ml bottles, and different bottle mouth distribution devices ensure that each use is appropriate, and the quality of the standard solution inside the bottle is not affected

8. RS-232 interface, optional barcode scanning

02Product Advantage

Efficient and accurate detection assistant - this detection equipment fully demonstrates its advantages

In testing work, efficiency and accuracy are often the core pursuits, and this testing equipment, with its many advantages, can bring great convenience to testing work.

From the perspective of detection efficiency, it can accommodate 24 samples at a time, with a testing time of only about 30 minutes. It can complete batch sample testing in a short period of time, greatly improving work progress.

In terms of sample processing, its advantages are particularly prominent. Only 30ul of sample is needed, which not only effectively saves samples, but also maintains good repeatability, ensuring the stability and reliability of the test results. At the same time, the equipment is equipped with a transparent sample observation window, which facilitates real-time observation of the sample status; The sample has independent space, coupled with the configuration of sample protection board, which can greatly reduce pollution and ensure the purity of the sample. Moreover, the sample tubes are reusable and easy to clean, which not only reduces usage costs but also minimizes waste generation.

In terms of operation and calibration, the equipment provides multiple calibration methods to meet the diverse needs of different users, making calibration work more flexible. In addition, it also has a sample probe cleaning function, which avoids the interference of residual substances on the probe on the detection results, further ensuring the accuracy of the detection.

In terms of the use of standard solution, the 125ml bottle of standard solution is paired with a proprietary bottle mouth distribution device to ensure that the amount taken each time is just right and will not affect the quality of the remaining standard solution in the bottle, ensuring the effectiveness of the standard solution and the accuracy of detection.

In terms of device compatibility and scalability, the device is equipped with an RS-232 interface and can also be optionally equipped with barcode scanning function, which facilitates data transmission and sample information management, and can better integrate into various testing workflows.

In summary, this testing equipment performs excellently in terms of efficiency, sample conservation, pollution prevention and control, and operational flexibility, making it a powerful assistant in testing work.

parameter

Model	2430/2430E
sample size	30µL
sample tube	plastic pipe
Number of sample disks	Up to 24
linear range	0-2000mOsmor 0-3000mOsm
precision	<2mOsm/kgH2O
Time/Measurement	50-70 seconds
cooling	About 5 minutes
cooling method	Thermoelectric,MetalBlock
calibration	Automatic Calibration -100500100015002000mOsm
Computer Output	RS232SerialPort
printer	20column,2¼”nonthermalpapertape
size	46x51x30cm
Gross Weight	11.3/8.6kg

standard configuration

Art.No.	List	Quty
2430	Machine	1
2050	LinCord	1
2096	InstructionManual	1
2038	pk30μLSampleTubes（qty500）	1
2035	AlignmentCard	1
2042	Carousel	1
2043	EvaporationShield	1
2053	rollPrinterPaper	1
2075	PrinterRibbon	1
2101	StandardSolution,100milliosmoles,125mlbottle	1
2105	StandardSolution,500milliosmoles,125mlbottle	1
2115	StandardSolution,1500milliosmoles,125mlbottle	1
2120	StandardSolution,2000milliosmoles,125mlbottle	1
2202	CONTROL290,290mOsmReferenceSolution,5mlampules，including10of290mOsmplus1eachof100&500mOsm	1

Transportation mode; Adopt appropriate transportation methods according to actual needs
